*UAP-AC-HD : UniFi AP HD 802.11ac Wave 2 2.4Ghz/5Ghz Enterprise Wi-Fi Access Point

คุณสมบัติสินค้า:

[ UAP-AC-HD ] รีวิว จำหน่าย ราคา Ubiquiti UniFi AP AC HD Wireless Access Point มาตรฐาน 802.11a/ac/ac-wave 2 ทำงานได้ทั้ง 2 คลื่นความถี่พร้อมกัน

หมวดหมู่ : UniFi Wireless Router Airmax

Share





Ubiquiti Networks ขอแนะนำ UAP-AC-HD Unifi Enterprise Wireless Access Point ที่มีรูปแบบทรงกลมคล้ายจานบิน มีเสาอากาศมาให้พร้อมในตัว มี RF Output Power 25dBm เหมาะสำหรับติดตั้งบนฝ้าเพดานหรือจะติดตั้งกับผนังก็ได้ และ UAP-AC-HD รุ่นนี้จะมาพร้อมกับมาตรฐานในการรับส่งข้อมูลชนิด 4X4 MU-Mimo 802.11ac Wave 2 Technology ซึ่งสามารถทำความเร็วในการรับ-ส่ง ข้อมูล โดยรวมได้ถึง 2533 Mbps

คุณสมบัติย่อของรุ่น UAP-AC-HD

  • Dual-Band Radio 4x4 Mu- MiMo
  • 5 GHz Band with Speeds of up to 1733 Mbps
  • 2.4 GHz Band with Speeds of up to 800 Mbps
  • รองรับผู้ใช้งานพร้อมกันได้ที่ 500+ Client
  • 802.3at PoE+ Compatibility
  • (2) Gigabit Ethernet Ports



Managed with the UniFi Network application: Version 6.2.26 and later





How to configuration




 วิธีการติดตั้ง



ฟังชั่นพื้นที่ฐานที่คุณสามารถใช้งานได้บนระบบปฎิบัติการ Unifi Os
• Operation mode (switching, mirroring, or aggregate) per port
• Network/VLAN configuration
• Jumbo frame and flow control services
• Network settings
• Storm control setting per port
• Spanning tree configuration
• 802.1X control and RADIUS VLAN
• Debug terminal option for command-line interface

การดูสถานะของ Switch Port Status  และนี่คือสิ่งที่คุณสามารถดูได้

• Connection speed and duplex mode
• TX/RX data rates
• Network/VLAN setting



การออกแบบที่ผสมผสาน

UniFi OS ถูกออกแบบมาเพื่อการใช้งานที่หลากหลาย โดยคุณสามารถบริหารจัดการอุปกรณ์ต่างๆ ได้จากหน้าจอ Unifi Controller เพียงหน้าจอเดียว นอกจากนี้แล้ว Unifi ยังมี Mobile App ให้คุณได้ใช้งานกันฟรีๆอีกด้วย



Network Application


Protect Application



Access Application ระบบควบคุมการเข้าออกประตู



Talk Application ระบบโทรศัพย์ผ่าน Internet







ควบคุมง่ายด้วย Mobile App

ในระบบ Unifi ก็มี Mobile App ให้คุณได้ใช้งานกันฟรีๆอีกด้วย













 ตารางคุณสมบัติจำเพาะ UAP-AC-HD
Dimensions220 x 220 x 48.1 mm
Weight
with Mounting Kits
700 g (24.7 oz)
830 g (29.3 oz)
Networking Interface(2) 10/100/1000 Ethernet Ports
Ports(2) Ethernet RJ45, (1) USB Type C
ButtonsReset
Antennas(2) 2.4G internal single band antennas, dual polarity
(2) 5G internal single band antennas, dual polarity
Wi-Fi Standards802.11a/b/g/n/ac/ac-wave2
Power MethodPoE 802.3at
Power SupplyPoE Injector 48VDC -0.5A Gigabit
Maximum Power Consumption17W
Max TX Power25 dBm
BSSID4 Per Radio
Power SaveSupported
Wireless SecurityWEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
CertificationsCE, FCC, IC
MountingWall/Ceiling (Kits Included)
Operating Temperature-10 to 70° C (14 to 158° F)
Operating Humidity5 to 95% Noncondensing

Advanced Traffic Management
VLAN802.1Q
Advanced QoSPer-User Rate Limiting
Guest Traffic IsolationSupported
WMMVoice, Video, Best Effort, and Background
Concurrent Clients500+



Supported Data Rates (Mbps)
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11ac6.5 Mbps to 1300 Mbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80)
802.11b1, 2, 5.5, 11 Mbps
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps



System Requirements สำหรับการติดตั้ง Unifi Controller
