USW-Mission-Critical Switch : 120W with Integrated 368Wh Battery Backup

คุณสมบัติสินค้า:

[ USW-Mission-Critical ] รีวิว จำหน่าย ราคา Ubiquiti Unifi Full managed Layer 2 Switch ที่ทำหน้าที่เป็น PoE Switch รวมทั้งมี Battery Backup ในตัว

หมวดหมู่ : UniFi Switching

Share

Ubiquiti Unifi USW-Mission-Critical (120W) เป็นสวิตช์ที่มาพร้อมกับแบตเตอรี่ลิเธียมไอออน 368Wh ในตัว ที่สามารถจ่ายไฟไม่ขาดสายให้กับอุปกรณ์ได้ถึง 8 ชิ้น มีทั้งพอร์ต GbE และ PoE+ รวมถึง PoE++ ที่รองรับการใช้งานที่หลากหลาย พร้อมหน้าจอสัมผัส LCM ขนาด 1.3 นิ้ว เหมาะสำหรับการใช้งานที่ต้องการความมั่นคงและเสถียรภาพสูง

คุณสมบัติเด่น

  • ประสิทธิภาพสูง : รองรับ throughput สูงสุด 450+ Mbps และลิงค์ระยะไกลมากกว่า 12 กม.
  • ความจุสูง : สามารถรองรับลูกค้าได้มากกว่า 50 ราย
  • แบตเตอรี่ในตัว : แบตเตอรี่ลิเธียมไอออน 368Wh สำหรับพลังงานสำรอง
  • การจัดการสะดวก : มีหน้าจอสัมผัส LCM และจัดการผ่าน Ethernet In-Band
  • รองรับ PoE : มีพอร์ต PoE+ และ PoE++ สำหรับจ่ายไฟให้อุปกรณ์ต่างๆ















UniFi OS ถูกออกแบบมาเพื่อการใช้งานที่หลากหลาย โดยคุณสามารถบริหารจัดการอุปกรณ์ต่างๆ ได้จากหน้าจอ Unifi Controller เพียงหน้าจอเดียว นอกจากนี้แล้ว Unifi ยังมี Mobile App ให้คุณได้ใช้งานกันฟรีๆอีกด้วย



Network Application


Protect Application



Access Application ระบบควบคุมการเข้าออกประตู



Talk Application ระบบโทรศัพย์ผ่าน Internet








USW-Mission-Critical
Dimensions442 x 480 x 44 mm (17.4 x 18.9 x 1.7")
WeightWithout Mount: 9.01 kg (19.86 lb)
With Mount: 9.2 kg (20.28 lb)
Enclosure MaterialSGCC Steel
Mount MaterialSGCC Steel


Hardware

Total Non-Blocking Throughput9 Gbps
Switching Capacity18 Gbps
Forwarding Rate26.78 Mpps
Max. Power Consumption240W
Max. Power Consumption (Excluding PoE Output)50W (10 + 40W Internal Chargers)
PoE Budget120W
Power Method(1) Universal AC input, 100-240VAC, 4.4A Max, 50/60 Hz
(1) DC Inputfor External 48VDC Battery
(1) Internal Lithium-Ion Battery, 368Wh
Power SupplyUniversal AC Input: AC/DC, Internal, 240W
External Battery Port: DC, External, 240W
Power Output(2) Power Control Outlets, 100-120VAC, 0.8A Max., 60Hz
Power Output Budget80W
Networking Interfaces(9) 10/100/1000 Mbps Ethernet RJ45 Ports
PoE Interfaces(4) PoE+ IEEE 802.3af/at(Pins 1, 2+; 3, 6-)
(4) 60W PoE++ IEEE 802.3bt(Pair A 1, 2+; 3, 6-)(Pair B 4, 5+; 7, 8-)
Max PoE+ Wattage per Port by PSE (AT)32W
Max PoE+ Wattage per Port by PSE (BT)64W
Voltage Range 802.3af Mode44-57V
Voltage Range 802.3at/bt Mode50-57V
LCM Display(1) 1.3" Touchscreen
Bootup Animation: Bootup in Progress
Firmware Upgrade Icon: Firmware Upgrading
Steady White: Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted
Management InterfaceEthernetIn-Band
ModesSMB Layer 2 PoE Gigabit Ethernet Switch
ESD/EMP ProtectionAir/Contact: ± 24 kV
Operating Temperature-5 to 40° C (23 to 104° F)
Operating Humidity-5 to 40° C (23 to 104° F)
CerticationsFCC, IC


LEDs

EthernetGreen: 1 Gbps, Amber: 10/100 Mbps
PoEAmber: IEEE 802.3af/at/bt
Power OutputBlue: Active

Switching Features

Layer 2 featuresIGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Layer 3 features
-
