UXG-Pro ,Dual-WAN security gateway ,Medium to large-sized networks with enterprise-class firewall

คุณสมบัติสินค้า:

[ UXG-Pro ] รีวิว จำหน่าย ราคา Unifi UXG-Pro คือ Security Gateway Router ในระดับ Enterprise Grade ที่สามารถทำหน้าที่เป็น Firewall ตรวจจับได้อีกด้วย

หมวดหมู่ : Unifi Cloud Key Security Gateway UniFi Switching

Share

UXG-Pro คือ Next-Generation Security Gateway Router ในระดับ Enterprise Grade ที่สามารถทำหน้าที่เป็น Firewall และตรวจจับผู้บุกรุก โดยตัวอุปกรณ์มี 2 Wan Port รองรับการทำ Failover รวมทั้งยังมี Power redundancy อีกด้วย

คุณสมบัติย่อ UXG-Pro

  • 1.7 GHz quad-core processor
  • (2) WAN ports (GbE RJ45 and 10G SFP+) with failover support
  • (2) LAN ports (GbE RJ45 and 10G SFP+)
  • Enterprise-class DPI, IPS/IDS, and layered firewall configuration
  • Power redundancy when connected to the UniFi SmartPower RPS (sold separately)
  • SmartPower outlet (125VAC/2A) for an external modem
  • 1U-sized, rack-mountable device



UniFi OS ถูกออกแบบมาเพื่อการใช้งานที่หลากหลาย โดยคุณสามารถบริหารจัดการอุปกรณ์ต่างๆ ได้จากหน้าจอ Unifi Controller เพียงหน้าจอเดียว นอกจากนี้แล้ว Unifi ยังมี Mobile App ให้คุณได้ใช้งานกันฟรีๆอีกด้วย



Network Application


Protect Application



Access Application ระบบควบคุมการเข้าออกประตู



Talk Application ระบบโทรศัพย์ผ่าน Internet









ตารางคุณสมบัติจำเพาะ UXG-Pro
Dimensions442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24")
Weight3.42 kg (7.54 lb)
Enclosure MaterialFront panel: aluminum CNC
Top cover/base: SGCC steel

Hardware

ProcessorQuad-core ARM® Cortex
®
-A57 at 1.7 GHz
Memory information2 GB DDR4
ManagementinterfaceEthernet
Networking interfaceLAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port
WAN:
(1) 1 GbE RJ45 port
(1) 10G SFP+ port
LCM display(1) 1.3" touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: rmware upgrading
ButtonFactory reset



Power methodUS(1) Universal AC input, 125VAC, 2.7A max., 60 Hz
(1) RPS DC input, 11.5VDC, 2.87A
Worldwide(1) Universal AC input, 200-240VAC, 1.7A max., 50/60 Hz
(1) RPS DC input, 11.5VDC, 2.87A



Power supplyAC/DC, internal, 50W
Max. power consumption30W
ESD/EMP protectionAir: ± 15 kV, contact: ± 8 kV
Operating temperature-10 to 40° C (14 to 104° F)
Operating humidity5 - 95% noncondensing
CertifcationsCE, FCC, IC

LEDs

AC outlet/ RPSBlue
EthernetGreen/amber
SFP+White/green
