RP-5AC : UISP airMAX Rocket Prism 5AC Radio
คุณสมบัติสินค้า:
[ RP-5AC ] รีวิว จำหน่าย ราคา RP-5AC คือ airMAX Rocket Prism 5AC เป็นอุปกรณ์ Access Point ที่มาพร้อมกับเทคโนโลยี RF Filter ที่เป็นเอกสิทธิ์เฉพาะ
หมวดหมู่ : Airmax , Access Point ,
Share
High-performance 5 GHz basestation for PtMP or PtP links. Provides up to 500+ Mbps data throughput
RP-5AC คืออุปกรณ์สำหรับงาน WISP ไม่ว่าจะเป็นงาน Point to Point หรือ งาน Point to Multi Point โดยอุปกรณ์รุ่นนี้จะมาพร้อมกับเทคโนโลยี RF Filter ที่เป็นเอกสิทธิ์เฉพาะของ Ubiquiti Airmax Chipset
คุณสามารถนำอุปกรณ์รุ่นนี้ไปต่อใช้งานร่วมกับ Antenna ชนิด Rocket Dish และ Sector Antenna
คุณสมบัติย่อ
- Custom Ubiquiti® airMAX AC Processor
- Proprietary airPrism® Active RF Filtering Technology
- GPS for Superior Co-Location Performance
- 5 GHz Wide Band Operating Frequency
- Point-to-MultiPoint Links to airMAX ac Clients
- Robust Die Cast Aluminum Casing
- Dedicated Management Radio
RP-5AC-Gen2 | |
| Mechanical | |
| Dimensions | 88 x 40 x 230 mm (3.47 x 1.58 x 9.06") |
| Weight | 400 g (14.11 oz) |
| Enclosure material | Die‑cast aluminum |
| Mounting | Pole mounting (kit Included) |
| Wind loading | 342.5 N at 200 km/h (77 lbf at 125 mph) |
| Hardware | |
| Processor | Atheros MIPS 74Kc |
| Memory | 128 MB DDR2 SDRAM |
| Networking interface | (1) 10/100/1000 MbE RJ45 port |
| RF Connectors | (2) RP-SMA (waterproof) (1) GPS* (waterproof) |
| Power method | Passive PoE (pairs 4, 5+; 7, 8 return) |
| Power supply | 24V, 1A Gigabit PoE adapter (Included) |
| Supported voltage range | 18—26V DC |
| Max. power consumption | 9.5W |
| LEDs | (4) Signal strength: software‑adjustable to correspond to custom RSSI levels GPS, LAN, power |
| RoHS compliance | Yes |
| Shock and vibrations | ETSI300-019-1.4 |
| Operating temperature | -40 to 80° C (-40 to 176° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
| Modes | Access Point, station |
| Channel sizes PtP mode PtMP mode | 10/20/30/40/50/60/80 MHz 10/20/30/40 MHz |
| Services | Web server, SNMP, SSH server, telnet , ping watchdog, DHCP, NAT, bridging, routing |
| Utilities | airMagic, airView, antenna alignment tool, discovery utility, site survey, ping, traceroute, speed test |
| Distance adjustment | Dynamic Ack and Ackless mode |
| Power adjustment | Software adjustable UI or CLI |
| Security | WPA2 AES only |
| QoS | Supports packet level classification WMM and user customer level: High/Medium/Low |
| Statistical reporting | Up time, packet errors, data rates, wireless distance, Ethernet link rate |
| Ubiquiti specific features | 30/50/60 MHz Channels, airMAX ac mode, traffic shaping with burst support, discovery protocol, frequency band offset, Ackless mode |
| Operating Frequency (MHz) | |
| Worldwide | 5150 ‑ 5875 MHz |
| USA U‑NII‑1: U‑NII‑2A: U‑NII‑2C: U-NII-3 | - 5150 ‑ 5250 MHz |
| Management Radio (MHz) | |
| Worldwide | 2412 ‑ 2472 MHz |
| USA | 2412 ‑ 2462 MHz |
